Applications

WarnMat® Underground Warning Tape

Warning tapes are commonly used for laying in underground trenches 200 mm above utilities like Gas line ,Electric power cable line Telecommunication cable line, Optical fibre cable line, water pipe line ,drainage water pipe line, Petroleum product pipe line etc for warning /identifying the utilities beneath.

WarnMat® Warning Mesh

Warning mesh are type 2 warning devices complying to EN 12613 standard used for laying in underground trenches 200 mm above utilities viz Gas line ,Electric power cable line Telecommunication cable line, Optical fibre cable line, water pipe line ,drainage water pipe line, Petroleum product pipe line etc for warning /identifying the utilities beneath.

WarmMat® ZIGMA Tape

Safety tapes serve important functions in the workplace. They highlight hazards, mark walkways and aisles. These safety tapes provide visual cues or instructions that make it easier for people to navigate through spaces. The two-tone stripe pattern comes in different color options so you can highlight different types of hazards

Promotional Tape

Promotional tapes are custom printed barrier tapes with promotional texts, logos, advertising ,warning etc to your unique design specifications.

WarnMat® Aluminium/steel Strip Detectable Tape

Detectable Marking Tape is used for detecting, locating, identifying, and protecting buried utility lines for gas, water, sewer, telecommunication, and electrical markets. The width of tape used, is determined by the size of, and depth at which the underground utility line is buried. The depth at which detectable tape is buried, is determined by the width of the tape used.

Aluminum/steel strip core 0.075 mm to 0.1mm thick is detected through means of inductive locating. Strip gives strength as well as larger cross section area of conductor enabling detection upto 1mt depth in harsher terrain.

WarnMat® Aluminium Foil Detectable Tape

These are also Detectable Marking Tape used for detecting, locating, identifying, and protecting buried utility lines for gas, water, sewer, telecommunication, and electrical markets. The width of tape used, is determined by the size of, and depth at which the underground utility line is buried.

Aluminium foil detectable Tape consists of a minimum 5.0 mil overall thickness. Construction is 0.8 mil clear virgin polypropylene film, reverse printed and laminated to a 0.35 solid aluminum foil core and then laminated to a 3.75 mil clear virgin polyethylene film.

Anti Corrosive SS Wires Detectable Tape

These are also Detectable Marking Tape used for detecting, locating, identifying, and protecting buried utility lines for gas, water, sewer, telecommunication, and electrical markets. The width of tape used, is determined by the size of, and depth at which the underground utility line is buried.

Anticorrosive Bopp tape coated copper /stainless steel wire are laminated on tape to make it conductive ,These tapes are also high strength due to metal wire reinforcement and work in any type of soil.

Barrier Tape / Caution Tape

These are the barrier tapes used for barricading areas in public space for avoiding danger.

NTR™ Warning Mat / Tape

  • These warning tapes, contains specialty rodent repellent nontoxic additives , for use in rodent prone soil for protecting tape from being chewed /cut by rodents.
  • These are warning tapes, containing specialty rodent repellent additives, for use in rodent prone soil for protecting tape from being chewed /cut by rodents .

Rodresist Tape

These are warning tapes, containing specialty rodent repellent additives, for use in rodent prone soil for protecting tape from being chewed /cut by rodents.

WarnMat® Warning Board/ Cable Protection Cover

Cable protection covers, tapetiles and underground warning tapes are installed over LV, MV and HV power cables in trench and ducted cable installations with high visibility colour providing a visual warning of danger when excavating cables. Cable Protection Cover are suitable for underground high voltage cable protection 22kV, 33kV, 66kV, 132kV and up to 400kV.

WarnMat® Tape Tile

Cable warning and protection rolls (Tape Tile) is rolled out into the cable trench for quick and easy protection of LV HV cables up to 11kV, street lighting, telecoms and fibre optic cables – Tape Tile is also suitable for underground gas and water pipe protection.

– Underground Cable Warning Tapes – used for LV 600/1000 Volts Cables

– Tapetile Cable Covers – used upto 11kV MV Medium Voltage Cables

– Cable Covers – used for 33kV 66kV 132kV HV High Voltage Cables

WarnMat® Warshield

Warshield is a heavy duty pipeline mesh that protects pipeline coatings from rock backfill. Warsheild is essential for projects installed in rocky terrain, offering high compression strength and resistance to destruction during and after the backfill process, minimizing pipeline coating damange and the resulting corrosion.

Compliance with APWA Standard

Colour Utility Line
White Proposed Excavation
Pink Temporary Survey Markings
Red Electrical Power Lines, Cables, Conduit and Lighting Cabless
Yellow Gas, Oil, Steam, Petroleum or Gaseous Materials
Orange Communication, Alarm or Signal Lines, Cables or Conduit
Purple Reclaimed Water, Irrigation and Slurry Lines
Green Sewer and Drain Line
Applications

APWA Uniform Color Code for Marking Underground Facilities

Underground facilities shall be marked in accordance with the following designated color code:

White
Pink
Red
Yellow
Orange
Blue
Purple
Green
